Merlin Gerin 685658CC replacement Closing Coil – BRAH BE-685658CC
BE-685658CC Closing Coil – view 1 of 3BE-685658CC Closing Coil – view 2 of 3BE-685658CC Closing Coil – view 3 of 3

Merlin Gerin 685658CC Replacement Closing Coil

BRAH BE-685658CC replaces the Merlin Gerin 685658CC closing coil: 220/250VAC, 200/220VDC, suitable for MP, 50/60Hz, for 800A - 5000A frames. Part of the Masterpact family. Covered by a BRAH Electric 2-year warranty; in-stock orders placed before 3:00 PM Pacific ship the same business day.

Factory New
Drop-in fit
Matches OEM Specs
In Stock
$658.33USD
1
2-Year Warranty included
(855) 355-2724Average waiting time: 1 min

Product Specifications

DatasheetCAD Doc (STEP)

685658CC, 220/250VAC, 200/220VDC closing coil, suitable for Merlin Gerin Masterpact insulated case type MP rated 800 amp - 5000 amp circuit breakers, direct substitute XF-E closing release for Merlin Gerin OEM 685658CC.

BRAH part: BE-685658CC

BE-685658CC specifications
BRAH Part NumberBE-685658CC
Replacement for OEM Part #685658CC
Replacement for OEM MfrMerlin Gerin
FamilyMasterpact
TypeMP
Voltage220/250VAC, 200/220VDC
Frequency (Hz)50/60Hz
Frame Type SuitableMP
Frame Size Suitable800A - 5000A

Frequently Asked Questions

Is this a direct drop-in replacement?
Yes. All BRAH Electric products are engineered as 1:1 direct replacements for the corresponding OEM part. No modifications, adapters, or special wiring are required for installation.*
*Exceptions may apply.
What warranty is included?
Every BRAH product ships with a 2-year warranty from the date of invoice. We guarantee proper function without defects according to provided specifications. Contact Kits carry a 6-month warranty.
Do you offer volume or bulk pricing?
Yes. If you are purchasing 10 or more units, or plan to buy regularly, you may qualify for our volume or reseller pricing program. Click on the product page or call us at (855) 355-2724.
What is your return policy?
Returns must be approved by a BRAH Electric representative with an RMA number. Returns within 30 days of shipment are subject to a restocking charge of 25–50%. Items are non-refundable after 30 days. Contact our support team to request an RMA. If you are unsure about product fit, call us at (855) 355-2724. See our Policies page for full details.
How fast will my order ship?
In-stock items ordered before 3:00 PM (Pacific) ship the same business day. You can see the live shipping countdown timer on the product page. Most domestic orders arrive within 2–5 business days.
Is this compatible with my Merlin Gerin breaker?
Yes. This BRAH replacement is engineered for direct compatibility with Merlin Gerin breakers and follows the same mounting and electrical specifications as the original part.
What OEM part numbers does BE-685658CC replace?
BE-685658CC is a direct replacement for 685658CC. No modifications or adapters are required—it installs like the original.
Is BE-685658CC a drop-in replacement for 685658CC?
Yes. BE-685658CC is a 1:1 drop-in replacement for 685658CC in Merlin Gerin applications. Same mounting and wiring.

Why purchase from BRAH Electric?

The new leader in aftermarket electrical parts. Trusted by more than 10k customers. Parts are tested at BRAH Electric's Carlsbad, California facility.

Rated 5.0 from 33 Google reviews (as of October 2026). Read our reviews on Google

Factory New
Drop-in fit
Matches OEM Specs
Ships Worldwide
2-Year Warranty included
